Product Description

The Titanium Plate is used to develop advanced equipment like heat exchangers, textile machinery and sports equipment. Apart from that, this product is extensively used in aviation sector, petrochemical industry, metallurgy sector and medical instrument production unit. Fabricated by using best quality titanium alloy, the manufacturing technique of this metal plate is in sync with ASTM specified standard of quality. As a quality conscious manufacturer and exporter of China, we are offering best quality Titanium Plate at lowest price range. Our capability includes customization of titanium plates on the basis of specifications provided by clients.

Application:

These are used in various applications including in heat exchangers, sporting equipment, textile machinery and different corrosive-resistant equipment.

Specifications

Product	Titanium and Titanium alloy plate & sheet
Material	Gr.1, Gr.2, Gr.3, Gr.4, Gr.5,Gr7,Gr9,Gr12 etc.
Standard	ASTM B265, ASME SB265, AMS 4911,ASTM F67,ASTM F136,etc.
Processing	Hot rolled, Cold rolled

Sizes :

Product	Thickness(mm)	Width(mm)	Length(mm)
Titanium Plate	5-8	2000 max	4000 max
Titanium Plate	8-100	3000 max	6000 max

Chemical components of each grade

Grade	Fe%	C%	N%	H%	O%	AI%	V%	Mo%	Ni%	Pd%	Ti
Gr1	0.2	0.08	0.03	0.015	0.18	--	-	-	-	-	BAL.
Gr2	0.3	0.08	0.03	0.015	0.25	-	-	-	-	-	BAL.
Gr3	0.3	0.08	0.05	0.015	0.35	-	-	-	-	-	BAL.
Gr4	0.3	0.08	0.05	0.015	0.40	-	-	-	-	-	BAL.
Gr5	0.25	0.08	0.03	0.015	0.02	5.5-6.75	3.5-4.5	-	-		BAL.
Gr7	0.3	0.08	0.03	0.015	0.25	-	-	-	-	0.12-0.25	BAL.
Gr9	0.25	0.08	0.03	0.015	0.15	2.5-3.3	2.0-3.0	-	-	-	BAL.
Gr12	0.3	0.08	0.03	0.015	0.25		-	0.2-0.4	0.6-0.9	-	BAL.
Gr23	0.3	0.08	0.03	0.015	0.13	5.5-6.75	-		-	-	BAL.

Mechanical characteristics of each grade

Grade	Tensile Strength (min)		Yield Strength 0.2% Offset		Elongation in 2 inch or 50mm % (min)
Grade	KSI	Mpa	KSI	MPa	Elongation in 2 inch or 50mm % (min)
Gr.1	35	240	20-45	138-310	24
Gr.2	50	345	40-65	275-450	20
Gr.3	65	450	55-80	380-550	18
Gr.4	80	550	> 70	> 483	15
Gr.5	138	950	> 128	> 880	14
Gr.7	50	345	> 40	> 275	24
Gr.9	125	860	> 105	> 725	10
Gr.12	70	483	> 50	> 345	18
Gr.23	125	860	> 115	> 790	15

Specifications:

Grade	Specification (mm)	Manufacturing Method	Condition	Standards
				Chine	Others
Gr1(TA1) Gr2(TA2) Gr3(TA3) Gr4(TA4) Gr5(TC4) Gr6(TA7) Gr7(TA9) Gr9(TA18) Gr1 1(TA9-1) Gr12(TA10) Gr23(TC4ELI)	(3.0~60) x (400~1000) x <3000 (5.0~60) x (1000~2000) x < 6000	Hot Rolled	M R	GB/T3621 GB/T14845 GB/T13810	ASTM 8265 SME 88265 AMS 4911 ASTMF67 ASTMF136 ISOS832-2 ISO5832-3 Other related standards
	(0.3~3.0) x (400~1000) x <3000 (0.1~0.3) x (100~500) x L (0.02~0.1) x (50~300) x L	Cold Rolled	M m Y
